Uni-prene A

Lightweight and very flexible single-layer neoprene hose with a temperature resistance from -50°C to +150°C. Designed primarily for conveying and extracting warm and cold air, gases, smoke and fumes. Suitable for industrial ventilation systems, pellet dryers, the automotive industry, exhaust gas extraction and other industrial applications.

Characteristics

Category:
Diameter:
19 – 305 mm
For the transport of media:
  • solids
  • gas
Application:
  • transport of loose materials
  • work at elevated temperatures
  • in ventilation systems
  • for industrial vacuum cleaners
  • for exhaust gas extraction
  • to extract chemical vapors
  • for the transport of granules
  • for municipal technologies
  • for agricultural equipment
  • for extracting hot gases
chemically resistant chemically resistant ✔️
thermal resistance thermal resistance -50 ÷ +150°C
flexibility flexibility ★★★★☆
standard lengths standard lengths 4 m

Profile

Technical parameters

All parameters listed in the table are specified for room temperature. The maximum tolerance range for the specified parameters is 5%. In order to discharge static electricity, the spiral must be grounded on both sides. Commercial hose lengths are measured in the fully extended state. Returns are accepted only for orders of standard commercial lengths. Depending on the type, diameter, and length, hoses are packaged either in a straight form, axially compressed, or coiled into rings, and then wrapped in stretch film or packed in cardboard boxes. Please inform us of your preferred hose packaging method when placing your order.
